Key Features
8 Steel
Turbo Combi Drying with sensor control
Auto Dose
Aqua Safe system
Flexiracks
XXL dishwashers
Crystal Glass
Light Lock
Self Cleaning
Vase/bottle holder
Time program
ECO wash
Status Light
Brushless motor
LED interior light
Green mode
Speed mode
Night Mode
Auto wash
Quick Pro Wash
Plastic wash
Lower half wash
Upper half wash
Rinse & hold
Aqua Level Sensor
Aqua Detect Sensor
Power Zone Cutlery
Kid Safe
Anti siphon
Extra wide knife stand
10 Spray
3 Level rack
Folding tines
Foldable Glass support
Telescopic rails
Removable middle rack
2 - Spray arms
Touch Proof
17 - Loading capacity
China Guard
15-3/4" plates in lower rack
Pop Out Door
Knife holders
Multi position glass rack
Focus points
Adjustable power zones
Push to open
Style
20 years
Quick Pro
Super Cleaning System (SCSâ„ ¢)
Documents
| Number of Boxes, Shipping Dimensions, & Shipping Weight | |
| Number of Boxes | 1 |
| Shipping Length | 26.75 in. |
| Shipping Width | 25.19 in. |
| Shipping Height | 36.63 in. |
| Shipping Weight | 146.5 lbs. |
| Total of Shipping Weight | 146.5 lbs. |
| Source | Calculation |
| Cubic Feet Measurement & Dimensional Weight | |
| Cubic Feet Measurement | 10.22 ft ³ |
| Total of Cubes | 10.22 ft ³ |
| Dimensional Weight | 127.01 lbs. |
| Total of Dimensional Weight | 127.01 lbs. |
| Construction and performance | |
| 8 Steelâ„ ¢ - Vital parts of the dishwasher made in stainless steel | Yes |
| No need to rinse the dishes thanks to Super Cleaning Systemâ„ ¢ | Yes |
| Automatic water-softener for better washing performance | Yes |
| Number of spray arms | 2 pcs |
| Number of spray zones | 10 |
| Cleaning systems | Twin Tubesâ„ ¢ - separate spray zone for the middle basket Cutlery Sprayâ„ ¢ - Extra dishwashing power for the cutlery basket No need to rinse the dishes thanks to Super Cleaning Systemâ„ ¢ Aqua |
| Use and flexibility | |
| Number of place settings | 17 pcs |
| Number of racks | 3 |
| Top tray | Without top tray |
| Upper rack type | Exclusive, all tines are foldable, divisble/foldable wine shelves, Light Lockâ„ ¢ for fastening lightweight items |
| Upper basket system | Easy height adjustable with lever |
| Upper basket | Dividable pin rows Wine glass fixings in TPE Sliding tines for easy adaptation to stone ware etc. Perfect ergonomy with easy sliding telescopic rails Light Lockâ„ ¢ for fastening lightweight i |
| Middle basket | Removable rack for large utensils Removable rack for bowls, cups and glasses Handle Middle basket connection fitted with non-return valve Perfect ergonomy with easy sliding telescopic rails |
| Lower rack type | Exclusive |
| Lower rack | Sliding tines for easy adaptation to stone ware etc. Cutlery basket Vase/bottle holder for cleaning vases/baby bottles Foldable/divisible front pin row Foldable/divisible rear pin row Handle |
| Automatic dosing system | Panel Ready |
| Interior light | Yes, 4 LED lights |
| Interaction and control | |
| Possible to control via Wi-Fi | Yes, integrated |
| Type of display | Graphic TFT display |
| Status Lightâ„ ¢ - Visual indication of dishwashing progress | Yes |
| Remaining time indication | Yes |
| Wash end indication | Displayed with sound and light |
| Language settings | Chinese simpified Chinese traditional Swedish Slovenian Slovak Russian Portuguese Polish Norwegian Dutch Latvian Lithuanian Japanese Italian Croatian French Finnish Estonian Spanish English G |
| Functions, programs and modes | |
| Programs | Anti odour Sanitize Light wash Self cleaning Quick Pro wash Crystal glass Lower half Upper half Rinse and hold programme Plastic wash Time program ECO wash Standard Auto wash Intensive progra |
| Delayed start | Possible to delay up to 24 hours |
| Options and modes | Heat Boost Mode Push to open - Handle-free door opening Sensor controlled door opening - Optimizes the drying process according to the room temperature Night mode - Lower noise level. The pro |
| Design and integration | |
| From the front adjustable door spring | Yes |
| From front adjustable rear foot | Yes |
| Installation | Velcro strips for easy mounting and adjustment of the separate custom door Multi fit outlet hose Integrated anti-siphon - Prevents spontaneous in- and outlet of water and simplifies elevated |
| Sliding door | No |
| Possible to install elevated | Yes |
| Custom door size | Custom door size 700-800 |
| Min. niche width | 24 '' |
| Min. niche height | 33 7/8 '' |
| Depth (incl. wall spacing) | 21 7/8 '' |
| Height setting | 2 1/16 '' |
| Adjustable kick plate | 30-94/0 |
| Safety and maintenance | |
| Aqua Safeâ„ ¢ | Anti Blockâ„ ¢ - Self cleaning drain pump Light and sound alarm Maximum time for water intake Extra durable PEX inlet hose Stand-by water protecion - Leakage detection when machine is off Aqua |
| Aqua Safeâ„ ¢ system | Yes |
| Child safety | Kid Safeâ„ ¢ - Lockable controls |
| Indication of low level of rinse-aid | Notification in display |
| Salt refill indicator | Notification in display |
| Technical data | |
| Water connection | Hot&cold water |
| Adapter for water connection | No |
| Max. temperature of inflow water | 140 Â °F |
| Noise level (max) | 39 dB(A) |
| Reference programme | 1 |
| Duration of standard programme | 125 min |
| Estimated yearly energy consumption | 220 kWh |
| Energy consumption - normal program | 1 kWh |
| Estimated annual water consumption | 647.5 gal |
| Water consumption | 3 gal |
| Power consumption in standby mode | 0.5 W |
| Plug type | USA |
| Connected load | 1300 W |
| Voltage (V) | 120 V |
| Number of phases | 1 |
| Fuse | 15 A |
| Frequency | 60 Hz |
| Required inlet water pressure psi | 0,03-1 |
| Net weight | 99.2 lb |
| Warranty | |
| Parts | 2 Year |
| Labor | 2 Year |
| Other | |
| Product code | 740096 |
| EAN code | 3838782634703 |
| Dimensions & Weight | |
| Width | 23.94 in. |
| Height | 33.81 in. |
| Length | 21.81 in. |
| Weight | 106.5 lbs. |
| Packaging width | 25 3/16 '' |
| Packaging height | 36 5/8 '' |
| Packaging depth | 26 3/4 '' |
| Gross weight | 106.5 lb |
| Maximum product height | 35 7/8 '' |
| Length of electrical cord | 71 7/16 '' |
| Depth with door open | 48 7/16 '' |
| Length inlet hose | 64 3/16 '' |
| Length outlet hose | 90 9/16 '' |
