Key Features
Super Cleaning Systemâ„¢ (SCSâ„¢)
8 Steelâ„¢
Aqua Safeâ„¢ system
Flexiracksâ„¢
XXL dishwashers
Crystal Glass
Light Lockâ„¢
Self Cleaning
Vase/bottle holder
Time program
ECO wash
Status Lightâ„¢
Brushless motor
LED interior light
Green mode
Speed mode
Night Mode
Intensive Mode
Auto wash
Plastic wash
Lower half wash
Upper half wash
Rinse & hold
Aqua Levelâ„¢ Sensor
Aqua Detectâ„¢ Sensor
Turbo Dryingâ„¢
Power Zone Cutleryâ„¢
Kid Safeâ„¢
Anti siphon
Jet Sprayâ„¢
Wide Sprayâ„¢
Extra wide knife stand
3 Level rack
Folding tines
Foldable Glass support
Telescopic rails
Removable middle rack
2 - Spray arms
Touch Proofâ„¢
17 - Loading capacity
China Guard
15-3/4" plates in lower rack
Knife holders
Multi position glass rack
20 years
Documents
| Number of Boxes, Shipping Dimensions, & Shipping Weight | |
| Number of Boxes | 1 |
| Shipping Length | 26.75 Inch |
| Shipping Width | 25.19 Inch |
| Shipping Height | 36.63 Inch |
| Shipping Weight | 149.3 lbs |
| Total of Shipping Weight | 149.3 lbs |
| Source | Manufacturer |
| Cubic Feet Measurement & Dimensional Weight | |
| Cubic Feet Measurement | 10.78 ft ³ |
| Total of Cubes | 10.78 ft ³ |
| Dimensional Weight | 134.04 Ibs |
| Total of Dimensional Weight | 134.04 Ibs |
| Construction and performance | |
| 8 Steelâ„¢ - Vital parts of the dishwasher made in stainless steel | Yes |
| No need to rinse the dishes thanks to Super Cleaning Systemâ„¢ | Yes |
| Automatic water-softener for better washing performance | No |
| Number of spray arms | 2 pcs |
| Cleaning systems | Jet Sprayâ„¢ - Extra dishwashing power for vases, bottles and baby bottles Wide Sprayâ„¢ - Extra dishwashing power for pots and pans Twin Tubesâ„¢ - separate spray zone for the middle basket Cutler |
| Exterior handle | SZW tubular handle |
| Use and flexibility | |
| Number of place settings | 17 pcs |
| Number of racks | 3 |
| Top tray | Without top tray |
| Upper rack type | Exclusive, all tines are foldable, divisble/foldable wine shelves, Light Lockâ„¢ for fastening lightweight items |
| Upper basket system | Easy height adjustable with lever |
| Upper basket | Foldable pin rows Perfect ergonomy with easy sliding telescopic rails Light Lockâ„¢ for fastening lightweight items China Guard - Protects fragile load from the rotating spray arm Extra wide kn |
| Middle basket | Removable rack for large utensils Removable rack for bowls, cups and glasses Handle Middle basket connection fitted with non-return valve Perfect ergonomy with easy sliding telescopic rails |
| Lower rack type | Exclusive |
| Lower rack | Cutlery basket Vase/bottle holder for cleaning vases/baby bottles Foldable/divisible front pin row Foldable/divisible rear pin row Handle with ASKO logo Handle Small distance between the bask |
| Automatic dosing system | No |
| Interior light | Yes, 4 LED lights |
| Interaction and control | |
| Possible to control via Wi-Fi | No |
| Type of display | LCD display |
| Status Lightâ„¢ - Visual indication of dishwashing progress | Yes |
| Remaining time indication | Yes |
| Wash end indication | Displayed with sound and light |
| Language settings | Chinese simpified Chinese traditional Swedish Slovenian Russian Portuguese Polish Norwegian Dutch Latvian Lithuanian Japanese Italian Croatian French Finnish Estonian Spanish English German D |
| Functions, programs and modes | |
| Programs | Sanitize Light wash Self cleaning Crystal glass Lower half Upper half Rinse and hold programme Plastic wash Time program ECO wash Standard Auto wash |
| Delayed start | Possible to delay up to 24 hours |
| Options and modes | Intensive mode - The dishwasher uses more heat and water. The program time is extended Night mode - Lower noise level. The program time is extended. Speed mode - The program time is shortened |
| Design and integration | |
| From the front adjustable door spring | No |
| From front adjustable rear foot | Yes |
| Installation | Multi fit outlet hose Integrated anti-siphon - Prevents spontaneous in- and outlet of water and simplifies elevated installation Trim kit Steam protection strip |
| Sliding door | No |
| Possible to install elevated | Yes |
| Min. niche width | 24 '' |
| Min. niche height | 33 7/8 '' |
| Depth (incl. wall spacing) | 22 5/8 '' |
| Height setting | 1 15/16 '' |
| Adjustable kick plate | 30-94/0 |
| Safety and maintenance | |
| Aqua Safeâ„¢ | Anti Blockâ„¢ - Self cleaning drain pump Light and sound alarm Maximum time for water intake Extra durable PEX inlet hose Stand-by water protecion - Leakage detection when machine is off Aqua L |
| Aqua Safeâ„¢ system | Yes |
| Child safety | Kid Safeâ„¢ - Lockable controls |
| Indication of low level of rinse-aid | Notification in display |
| Technical data | |
| Water connection | Hot&cold water |
| Adapter for water connection | No |
| Max. temperature of inflow water | 140 °F |
| Noise level (max) | 40 dB(A) |
| Reference programme | 1 |
| Estimated yearly energy consumption | 235 kWh |
| Energy consumption - normal program | 1 kWh |
| Estimated annual water consumption | 687.4 gal |
| Water consumption | 3.2 gal |
| Power consumption in standby mode | 0.49 W |
| Consumption in off mode | 0.49 W |
| Plug type | USA |
| Connected load | 1300 W |
| Voltage (V) | 120 V |
| Number of phases | 1 |
| Fuse | 15 A |
| Frequency | 60 Hz |
| Required inlet water pressure psi | 0,03-1 |
| Net weight | 101.4 lb |
| Dimensions | |
| Width | 24 '' |
| Height | 34 5/16 '' |
| Depth | 22 5/8 '' |
| Maximum product height | 36 1/4 '' |
| Length of electrical cord | 47 1/4 '' |
| Depth with door open | 49 5/16 '' |
| Length inlet hose | 64 3/16 '' |
| Length outlet hose | 90 9/16 '' |
| Logistic information | |
| Packaging width | 25 3/16 '' |
| Packaging height | 36 5/8 '' |
| Packaging depth | 26 3/4 '' |
| Gross weight | 109.3 lb |
| Product code | 737068 |
| EAN code | 3838782511844 |
