Key Features
8 Steel
Aqua Safe system
Flexiracks
XXL dishwashers
Crystal Glass
Light Lock
Self Cleaning
Vase/bottle holder
Time program
ECO wash
Status Light
Brushless motor
LED interior light
Green mode
Speed mode
Night Mode
Intensive Mode
Auto wash
Plastic wash
Lower half wash
Upper half wash
Rinse & hold
Aqua Level Sensor
Aqua Detect Sensor
Turbo Drying
Power Zone Cutlery
Kid Safe
Anti siphon
Jet Spray
Wide Spray
Extra wide knife stand
3 Level rack
Folding tines
Foldable Glass support
Telescopic rails
Removable middle rack
2 - Spray arms
Touch Proof
17 - Loading capacity
China Guard
15-3/4" plates in lower rack
Knife holders
Multi position glass rack
20 years
Super Cleaning System (SCSâ„ ¢)
Documents
| Number of Boxes, Shipping Dimensions, & Shipping Weight | |
| Number of Boxes | 1 |
| Shipping Length | 26.75 in. |
| Shipping Width | 25.19 in. |
| Shipping Height | 36.63 in. |
| Shipping Weight | 148.2 lbs. |
| Total of Shipping Weight | 148.2 lbs. |
| Source | Calculation |
| Cubic Feet Measurement & Dimensional Weight | |
| Cubic Feet Measurement | 10.78 ft ³ |
| Total of Cubes | 10.78 ft ³ |
| Dimensional Weight | 134.04 lbs. |
| Total of Dimensional Weight | 134.04 lbs. |
| Construction and performance | |
| 8 Steelâ„ ¢ - Vital parts of the dishwasher made in stainless steel | Yes |
| No need to rinse the dishes thanks to Super Cleaning Systemâ„ ¢ | Yes |
| Automatic water-softener for better washing performance | No |
| Number of spray arms | 2 pcs |
| Cleaning systems | Jet Sprayâ„ ¢ - Extra dishwashing power for vases, bottles and baby bottles Wide Sprayâ„ ¢ - Extra dishwashing power for pots and pans Twin Tubesâ„ ¢ - separate spray zone for the middle basket |
| Exterior handle | |
| Use and flexibility | |
| Number of place settings | 17 pcs |
| Number of racks | 3 |
| Top tray | Without top tray |
| Upper rack type | Exclusive, all tines are foldable, divisble/foldable wine shelves, Light Lockâ„ ¢ for fastening lightweight items |
| Upper rack height adjustable | Yes |
| Upper basket | Perfect ergonomy with easy sliding telescopic rails Small distance between the basket threads - makes loading easy and prevents small items to fall through Light Lockâ„ ¢ for fastening lightwe |
| Middle basket | Perfect ergonomy with easy sliding telescopic rails Removable rack for bowls, cups and glasses Removable rack for large utensils Middle basket connection fitted with non-return valve Handle |
| Lower rack type | Exclusive |
| Lower rack | Foldable/divisible rear pin row Vase/bottle holder for cleaning vases/baby bottles Foldable/divisible front pin row Cutlery basket Handle Small distance between the basket threads - makes loa |
| Automatic dosing system | No |
| Interior light | Yes, 4 LED lights |
| Interaction and control | |
| Possible to control via Wi-Fi | No |
| Type of display | LCD display |
| Status Lightâ„ ¢ - Visual indication of dishwashing progress | Yes |
| Remaining time indication | Yes |
| Wash end indication | Displayed with sound and light |
| Language settings | Norwegian German Swedish Russian Finnish Portuguese Lithuanian English Latvian Croatian Italian French Chinese traditional Spanish Estonian Japanese Chinese simpified Slovenian Polish Danish |
| Functions, programs and modes | |
| Programs | Rinse and hold programme Upper half Sanitize Lower half Auto wash Standard Crystal glass Time program ECO wash Self cleaning Light wash Plastic wash |
| Delayed start | Possible to delay up to 24 hours |
| Options and modes | Time set Extra dry - Improves the drying result Green mode - Less energy and water is used. The program time is extended Speed mode - The program time is shortened. More energy is used. Night |
| Design and integration | |
| From the front adjustable door spring | No |
| From front adjustable rear foot | Yes |
| Installation | Multi fit outlet hose Integrated anti-siphon - Prevents spontaneous in- and outlet of water and simplifies elevated installation Trim kit Steam protection strip |
| Sliding door | No |
| Possible to install elevated | Yes |
| Min. niche width | 24 '' |
| Min. niche height | 33 7/8 '' |
| Depth (incl. wall spacing) | 22 5/8 '' |
| Height setting | 1 15/16 '' |
| Adjustable kick plate | 30-94/0 |
| Safety and maintenance | |
| Aqua Safeâ„ ¢ | Sealing points outside container Extra durable stainless steel container Waterproof bottom plate Detection of water leakage on the bottom plate Aqua Detectâ„ ¢ - Instant recognition of any lea |
| Aqua Safeâ„ ¢ system | Yes |
| Child safety | Kid Safeâ„ ¢ - Lockable controls |
| Indication of low level of rinse-aid | Notification in display |
| Technical data | |
| Water connection | Hot&cold water |
| Adapter for water connection | No |
| Max. temperature of inflow water | 140 Â °F |
| Noise level (max) | 40 dB(A) |
| Reference programme | 1 |
| Estimated yearly energy consumption | 235 kWh |
| Energy consumption - normal program | 1 kWh |
| Estimated annual water consumption | 687.4 gal |
| Water consumption | 3.2 gal |
| Power consumption in standby mode | 0.49 W |
| Consumption in off mode | 0.49 W |
| Plug type | USA |
| Connected load | 1300 W |
| Voltage (V) | 120 V |
| Number of phases | 1 |
| Fuse | 15 A |
| Frequency | 60 Hz |
| Required inlet water pressure psi | 0,03-1 |
| Net weight | 100.3 lb |
| Other | |
| Product code | 738570 |
| EAN code | 3838782518423 |
| Dimensions & Weight | |
| Width | 24 in. |
| Height | 34.31 in. |
| Length | 22.63 in. |
| Weight | 108.2 lbs. |
| Packaging width | 25 3/16 '' |
| Packaging height | 36 5/8 '' |
| Packaging depth | 26 3/4 '' |
| Gross weight | 108.2 lb |
| Maximum product height | 36 1/4 '' |
| Length of electrical cord | 47 1/4 '' |
| Depth with door open | 49 5/16 '' |
| Length inlet hose | 64 3/16 '' |
| Length outlet hose | 90 9/16 '' |
