Key Features
8 Steel
Aqua Safe system
Flexiracks
XL dishwashers
Light Lock
Self Cleaning
Vase/bottle holder
Top cutlery tray
Time program
Status Light
Brushless motor
LED interior light
Green mode
Speed mode
Night Mode
Auto wash
Quick Pro Wash
Rinse & hold
Aqua Level Sensor
Aqua Detect Sensor
Power Zone Cutlery
Kid Safe
Anti siphon
Extra wide knife stand
Instant Lift
9 Spray
3 Level rack
Folding tines
Foldable Glass support
Telescopic rails
Sliding Door
3 - Spray arms
Condensation dry
16 - Loading capacity
China Guard
Pop Out Door
Knife holders
Multi position glass rack
Focus points
Adjustable power zones
Logic
20 years
Quick Pro
Super Cleaning System (SCSâ„ ¢)
Documents
| Number of Boxes, Shipping Dimensions, & Shipping Weight | |
| Number of Boxes | 1 |
| Shipping Length | 26.75 in. |
| Shipping Width | 25.19 in. |
| Shipping Height | 35.06 in. |
| Shipping Weight | 137 lbs. |
| Total of Shipping Weight | 137 lbs. |
| Source | Calculation |
| Cubic Feet Measurement & Dimensional Weight | |
| Cubic Feet Measurement | 9.74 ft ³ |
| Total of Cubes | 9.74 ft ³ |
| Dimensional Weight | 121.14 lbs. |
| Total of Dimensional Weight | 121.14 lbs. |
| Construction and performance | |
| 8 Steelâ„ ¢ - Vital parts of the dishwasher made in stainless steel | Yes |
| No need to rinse the dishes thanks to Super Cleaning Systemâ„ ¢ | Yes |
| Automatic water-softener for better washing performance | No |
| Number of spray arms | 3 pcs |
| Number of spray zones | 9 |
| Cleaning systems | Cutlery Sprayâ„ ¢ - Extra dishwashing power for the cutlery basket No need to rinse the dishes thanks to Super Cleaning Systemâ„ ¢ Aqua Levelâ„ ¢ Sensor Sensi Cleanâ„ ¢ Sensor - measures dirtines |
| Use and flexibility | |
| Number of place settings | 16 pcs |
| Number of racks | 3 |
| Top tray | Easy height adjustment With telescopic rails Handle Removable Guide rails with ball bearings |
| Upper rack type | Exclusive, all tines are foldable, divisble/foldable wine shelves, Light Lockâ„ ¢ for fastening lightweight items |
| Upper basket system | Easy height adjustable with lever |
| Upper basket | Dividable pin rows Wine glass fixings in TPE Sliding tines for easy adaptation to stone ware etc. Perfect ergonomy with easy sliding telescopic rails Light Lockâ„ ¢ for fastening lightweight i |
| Middle basket | Without middle basket |
| Lower rack type | Exclusive |
| Lower rack | Sliding tines for easy adaptation to stone ware etc. Cutlery basket Vase/bottle holder for cleaning vases/baby bottles Foldable/divisible front pin row Foldable/divisible rear pin row Handle |
| Automatic dosing system | No |
| Interior light | Yes, 2 LED lights |
| Interaction and control | |
| Possible to control via Wi-Fi | Yes, integrated |
| Type of display | LCD display |
| Status Lightâ„ ¢ - Visual indication of dishwashing progress | Yes |
| Remaining time indication | Yes |
| Wash end indication | Displayed with sound and light |
| Language settings | Chinese simpified Chinese traditional Swedish Slovenian Slovak Russian Portuguese Polish Norwegian Dutch Latvian Lithuanian Japanese Italian Croatian French Finnish Estonian Spanish English G |
| Functions, programs and modes | |
| Programs | Intensive program Auto wash Standard Time program Rinse and hold programme Quick Pro wash Self cleaning Sanitize |
| Delayed start | Possible to delay up to 24 hours |
| Options and modes | Heat Boost Mode Night mode - Lower noise level. The program time is extended. Speed mode - The program time is shortened. More energy is used. Green mode - Less energy and water is used. The |
| Design and integration | |
| From the front adjustable door spring | Yes |
| From front adjustable rear foot | Yes |
| Installation | Velcro strips for easy mounting and adjustment of the separate custom door Multi fit outlet hose Integrated anti-siphon - Prevents spontaneous in- and outlet of water and simplifies elevated |
| Sliding door | Yes |
| Possible to install elevated | Yes |
| Custom door size | Custom door size 720-800 |
| Min. niche width | 24 '' |
| Min. niche height | 32 5/16 '' |
| Depth (incl. wall spacing) | 21 7/8 '' |
| Height setting | 2 1/16 '' |
| Safety and maintenance | |
| Aqua Safeâ„ ¢ | Anti Blockâ„ ¢ - Self cleaning drain pump Light and sound alarm Maximum time for water intake Extra durable PEX inlet hose Stand-by water protecion - Leakage detection when machine is off Aqua |
| Aqua Safeâ„ ¢ system | Yes |
| Child safety | Kid Safeâ„ ¢ - Lockable controls |
| Indication of low level of rinse-aid | Notification in display |
| Technical data | |
| Water connection | Hot&cold water |
| Adapter for water connection | No |
| Max. temperature of inflow water | 140 Â °F |
| Noise level (max) | 40 dB(A) |
| Reference programme | 1 |
| Duration of standard programme | 125 min |
| Estimated yearly energy consumption | 220 kWh |
| Energy consumption - normal program | 1 kWh |
| Estimated annual water consumption | 647.5 gal |
| Water consumption | 3 gal |
| Power consumption in standby mode | 0.5 W |
| Plug type | USA |
| Connected load | 1300 W |
| Voltage (V) | 120 V |
| Number of phases | 1 |
| Fuse | 15 A |
| Frequency | 60 Hz |
| Required inlet water pressure psi | 0,03-1 |
| Net weight | 90.4 lb |
| ISO 9001 certified manufacturer | Yes |
| Warranty | |
| Parts | 2 Year |
| Labor | 2 Year |
| Other | |
| Product code | 740098 |
| EAN code | 3838782650666 |
| Dimensions & Weight | |
| Width | 23.94 in. |
| Height | 32.25 in. |
| Length | 21.81 in. |
| Weight | 97 lbs. |
| Packaging width | 25 3/16 '' |
| Packaging height | 35 1/16 '' |
| Packaging depth | 26 3/4 '' |
| Gross weight | 97 lb |
| Maximum product height | 34 5/16 '' |
| Length of electrical cord | 71 7/16 '' |
| Depth with door open | 48 15/16 '' |
| Length inlet hose | 64 3/16 '' |
| Length outlet hose | 90 9/16 '' |
