Key Features
Depth:22''
Very quiet 1.2 Sones at normal speed.
Powered by internal blower system with 675 Max Blower CFM
4-speed electronic controls, 10 minute delay-off feature keeps hood running after cooking to ensure smoke & odors have cleared the environment, and the filter clean reminder helps ensure optimal performance.
Width: 36''
8" round duct connector with backdraft damper.
Can be used with optional Universal make-up air damper MD6TU, MD8TU or MD10TU to replace air exhausted out of the house only when the hood is turned ON, helping with ventilation to keep your home fresh while reducing energy consumption
Three-levels halogen cooktop lighting. Bulbs included.
Quick release, dishwasher-safe mesh grease filters ensure clean, fresh kitchen
Recirculation kit ANKWTT326Â is available for installations where ducting to outdoors is not possible
Non-ducted capability
Heat Sentry detects excessive heat and adjusts blower speed to high automatically to prolong product life by reducing damaging effects of high temperatures
Documents
| Number of Boxes, Shipping Dimensions, & Shipping Weight | |
| Number of Boxes | 1 |
| Shipping Length | 27 in. |
| Shipping Width | 41 in. |
| Shipping Height | 32.75 in. |
| Shipping Weight | - |
| Total of Shipping Weight | - |
| Source | Calculation |
| Cubic Feet Measurement & Dimensional Weight | |
| Cubic Feet Measurement | 12.72 ft ³ |
| Total of Cubes | 12.72 ft ³ |
| Dimensional Weight | 158.12 Ibs |
| Total of Dimensional Weight | 158.12 Ibs |
| Other | |
| Finish | Stainless Steel |
| Material | Stainless Steel |
| Sound Level (Sones) | Yes |
| Max Blower CFM | 675 |
| Lighting Type | Halogen |
| Light Bulbs Included | Yes |
| Control Type | Electronic Pushbutton |
| Speed Levels | 4 |
| Lighting Level | 3 |
| Filter Type | Aluminum Mesh |
| Heat Sentry | Yes |
| Remote Operation Capable | No |
| Can be used to comply with LEED Requirements | Yes |
| Manufacturer Warranty | 5 Year Parts/2 Year Labor |
| ENERGY STARÂ ® certified | No |
| Dimensions & Weight | |
| Width | 36 in. |
| Height | 27.75 in. |
| Length | 22 in. |
| Weight | - |
